80PLUS PLATINUMEfficiency
ATX 12V 3.1Type
160(L)*150(W)*86(H)Dimension
Full-ModularModular
Specifications
The details
| Brand | Antec |
|---|---|
| Warranty | 10 Year Warranty |
| Efficiency | 80PLUS PLATINUM |
| Model | HCG1000 PRO Platinum ATX3.1 |
| Type | ATX 12V 3.1 |
| Dimension | 160(L)*150(W)*86(H) |
| Modular | Full-Modular |
| Warranty | 10 years |
| Input Voltage | 100V-240V |
| Input Current | 13A-6.5A |
| Input Frequency Range | 60Hz-50Hz |
| PFC | Active PFC |
| Power Good Signal | 100-150ms |
| Protection | OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO |
| Output Capacity | 1000W |
| Operation Temperature | 0~40°C |
| Regulatoryc | TUVus/TUV/CB/RCM/CE/FCC/BIS/BSMI/KC/UKCA/ICES/CCC |
| Fan | 135mm FDB Silent Fan |
| Certifications | 80 Plus Platinum |
| Connector | 1 x 24(20+4)pin MB |
| 3 x Molex | |
| Unit Box Dimensions | 336mm*198mm*133mm |
| Shipping Box Dimensions | 600mm*200mm*375mm |
| Net Weight | 3.39kg |
| Gross Weight | 3.97kg |
About this product
Description
- 1 x 16(12+4)pin PCIE 5.1 12V-2x6
- 2 x 8(4+4)pin CPU
- 3 x 8(6+2) Pin PCI-E
- 14 x SATA
