ASUS PRIME A320M-K MOTHERBOARD
AMD AM4Socket Type
AMD A320Chipset
HDMI/RGB portsMulti-VGA output support
Specifications

The details

BrandASUS
Warranty03 YEAR WARRANTY
Socket TypeAMD AM4
ChipsetAMD A320
Multi-VGA output supportHDMI/RGB ports
Special Features
– ASUS SafeSlot CoreFortified PCIe Slot prevents damage
– ASUS Overvoltage ProtectionWorld-class circuit-protecting power design
– ASUS Stainless-Steel Back I/O3X corrosion-resistance for greater durability!
– ASUS DIGI+ VRM6 Phase digital power design, – AI Suite 3, – Ai Charger, – Stylish Fanless Design Heat-sink solution, – ASUS Fan Xpert, – ASUS CrashFree BIOS 3, – ASUS EZ Flash 3, – ASUS UEFI BIOS EZ Mode, – Multi-language BIOS, – ASUS Q-Slot, – ASUS Q-DIMM, Operating System Support, Windows® 10 , 64bit, Back I/O Ports, 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x D-Sub, 1 x HDMI, 1 x LAN (RJ45) port(s), 4 x USB 3.1 Gen 1 (blue) ,, 2 x USB 2.0, 3 x Audio jack(s), Internal I/O Ports, 1 x COM port(s)
About this product

Description

AMD AM4 Socket Ryzen™ with Radeon™ Vega Graphics/Ryzen™ 1st Generation/7th Generation A-series/Athlon X4 Processors

  • Supports CPU up to 8 cores
  • * Refer to www.asus.com for CPU support list
  • Chipset
  • AMD A320
  • Memory
  • AMD Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors
  • 2 x DIMM, Max. 32GB, DDR4 3200(O.C.)/2933(O.C.)/2666/2400/2133 MHz Un-buffered Memory
  • AMD 7th Generation A-Series/Athlon X4 Processors
  • 2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Un-buffered Memory
  • Dual Channel Memory Architecture
  • * Hyper DIMM support is subject to the physical characteristics of individual CPUs.
  • * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
  • Graphic
  • Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics/ 7th Generation A-Series APU
  • – Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
  • – Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
  • Maximum shared memory of 2048 MB (for iGPU exclusively)
  • Expansion Slots
  • AMD Ryzen™ 1st Generation Processors
  • 1 x PCIe 3.0/2.0 x16 (x16 or dual x8)
  • AMD Ryzen™ with Radeon™ Vega Graphics /7th Generation A-Series/Athlon X4 Processors
  • 1 x PCIe 3.0/2.0 x16 (x8 mode)
  • AMD A320 chipset
  • 2 x PCIe 2.0 x1
  • Storage
  • 4 x SATA 6Gb/s port(s), gray,
  • Support Raid 0, 1, 10
  • 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  • 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)
  • Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
  • Audio
  • Realtek® ALC887 8-Channel High Definition Audio CODEC
  • USB Ports

AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/7th Generation A-Series/Athlon X4 Processors :

  • 4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
  • 2 x USB 3.0 port(s) (2 at mid-board)
  • 6 x USB 2.0 port(s) (2 at back panel, , 4 at mid-board)
  • – ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
  • 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
  • 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  • 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
