AMD AM4Socket Type
AMD A520Chipset
8111H 1Gb EthernetRealtek RTL
GuardASUS LAN
Specifications
The details
| Brand | ASUS |
|---|---|
| Warranty | 03 YEAR WARRANTY |
| Socket Type | AMD AM4 |
| Chipset | AMD A520 |
| Comprehensive cooling | PCH heatsink and Fan Xpert |
| Ultrafast connectivity | M.2 support, 1 Gb Ethernet, USB 3.2 Gen 2 Type-A |
| 5X Protection III | Multiple hardware safeguards for all-around system protection |
| Support Raid 0, 1, 10 | |
| Realtek RTL | 8111H 1Gb Ethernet |
| ASUS LAN | Guard |
| Audio | |
| Realtek ALC | 887/897 7.1 Surround Sound High Definition Audio CODEC *, - LED-illuminated design, - Audio Shielding, - Dedicated audio PCB layers, - Premium Japanese audio capacitors, USB Ports, Rear USB Port ( Total 7 ), 1 x USB 3.2 Gen 2 port(s), 4 x USB 3.2 Gen 1 port(s)(4 x Type-A), 2 x USB 2.0 port(s)(2 x Type-A), Front USB Port ( Total 6 ), 2 x USB 3.2 Gen 1 port(s)(2 x Type-A), 4 x USB 2.0 port(s)(4 x Type-A), Software Features, ASUS Exclusive Software, Armoury Crate, AI Suite 3, - Performance and Powe |
| Turbo | V EVO, Digi+ VRM, Fan Xpert, - EZ update, ASUS CPU-Z, AI Charger, DAEMON Tools, Norton Anti-virus software (Free Trial for 60 days) |
| Win | RAR, - ASUS CrashFree BIOS 3, - ASUS EZ Flash 3, - ASUS UEFI BIOS EZ Mode, ASUS Special Features, ASUS 5X PROTECTION III, - ASUS DIGI+ VRM, - ASUS LANGuard, - ASUS Overvoltage Protection, - ASUS SafeSlot Core, - ASUS Stainless-Steel Back I/O, ASUS Q-Design, - ASUS Q-DIMM, - ASUS Q-Slot, ASUS Thermal Solution, - Aluminum heatsink design, ASUS Lighting Control, Back I/O Ports, 1 x PS/2 keyboard/mouse combo port(s), 1 x HDMI, 1 x LAN (RJ45) port(s) |
About this product
Description
- AMD AM4 socket: Ready for Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors
- AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors *
- * Refer to www.asus.com for CPU support list
- Chipset
- AMD A520
- Memory
2 x DIMM, Max. 64GB, DDR4 4866(O.C)/4600(O.C)/4466(O.C.)/4400(O.C)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory *
- Dual Channel Memory Architecture
- ECC Memory (ECC mode) support varies by CPU.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.
- Graphic
- 1 x D-Sub
- 1 x DVI-D
- 1 x HDMI 2.1(4K@60HZ)
- Expansion Slots
- AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
- 1 x PCIe 3.0 x16 (x16 mode)
- AMD A520 Chipset
- 2 x PCIe 3.0 x1
- Storage
- Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports
- 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
- 4 x SATA 6Gb/s port(s),
- - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
- * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
