The details
| Brand | ASUS |
|---|---|
| Warranty | 3 Years Warranty |
| Socket Type | AMD AM5 |
| Chipset | INTEL B760 |
| Model | |
| Pro | Art X670E-CREATOR WIFI |
| AMD Socket AM | 5 for AMD Ryzen™ 7000 Series Desktop Processors*, Chipset, AMD X670, Memory, Dual Channel Memory Architecture, Supports AMD Extended Profiles for Overclocking (EXPO™) |
| Opti | Mem II, Graphics, 1 x HDMI® port**, 2 x USB4® ports support USB Type-C® display outputs***, Expansion Slots, AMD Ryzen™ 7000 Series Desktop Processors*, 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes), AMD X670 Chipset, 1 x PCIe 4.0 x16 slot (supports x2 mode)**, Storage, Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*, AMD Ryzen™ 7000 Series Desktop Processors, 4 x SATA 6Gb/s ports, Ethernet, 1 x Marvell® AQtion 10Gb Ethernet |
| 1 x Intel® 2.5Gb Ethernet | |
| ASUS LAN | Guard, Wireless & Bluetooth, Wi-Fi 6E, 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), Supports 2.4/5/6GHz frequency band*, Bluetooth® v5.2 |
| Bluetooth v | 5.2, Rear USB (Total 11 ports), 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 7 x USB 3.2 Gen 2 ports (7 x Type-A), 1 x USB 2.0 port (1 x Type-A), Front USB (Total 9 ports), 3 x USB 2.0 headers support 6 additional USB 2.0 ports, Audio, - Impedance sense for front and rear headphone outputs |
| - Supports | Jack-detection, Multi-streaming, Front Panel Jack-retasking, - Supports up to 32-Bit/192 kHz playback*, Audio Features, - Premium audio capacitors, - Dedicated audio PCB layers, - Audio cover, - Unique de-pop circuit, Back Panel I/O Ports, 1 x DisplayPort (Input only), 1 x HDMI® port, 1 x Wi-Fi Module |
Description
The ProArt X670E-Creator WiFi empowers creators of all levels by maximizing the performance of the latest AMD Ryzen™ 7000 Series processors with 16+2 team power stages, DDR5 and PCIe 5.0 and lightning-fast connectivity including USB4®, 10 Gb and 2.5 Gb Ethernet, plus WiFi 6E.
It manifests a professional, elegant and precise vision for content creators of all kinds with a style elevated by tone-on-tone layers of black infused with metallic gold touches. A translucent I/O cover also gives users a stylish peek at the premium connectors within.
- * Refer to www.asus.com for CPU support list.
4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory*
* Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
- ** Non-ECC, Un-buffered DDR5 Memroy supports On-Die ECC function.
- * Graphics specifications may vary between CPU types.
- ** Supports 4K@60Hz as specified in HDMI 2.1.
- *** Supports max. 8K@60Hz as specified in DisplayPort 1.4.
**** Output at USB4_EC1 and USB4_EC2, each requires a USB-C® to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution.
- * Please check the PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/).
- ** PCIEX16_3 shares bandwidth with M.2_3 slot. Please adjust in BIOS setting to enable PCIEX16_3.
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
- M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)**
- M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
- *AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.
** M.2_3 slot shares bandwidth with PCIEX16_3. When PCIEX16_3 is in operation after adjusting in BIOS settings, M.2_3 slot will only run at PCIe x2 mode.
- * WiFi 6E 6GHz regulatory may vary between countries.
- 2 x USB4® with Intel® JHL8540 USB4® controller ports (2 x USB Type-C®)
- 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C® with up to 60W PD/QC4+)
- 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
- Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC*
- - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- - Power pre-regulator reduces power input noise to ensure consistent performance
- * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
