AMD AM4Socket Type
AMD B550Chipset
5.2Bluetooth v
Specifications
The details
| Brand | ASUS |
|---|---|
| Socket Type | AMD AM4 |
| Chipset | AMD B550 |
| 1 x Intel® I225-V 2.5Gb Ethernet | |
| ASUS LAN | Guard, Wi-Fi 6E, 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), Supports 2.4/5/6GHz frequency band* |
| Bluetooth v | 5.2 |
| Rear USB | Total 8 ports2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C®), 4 x USB 3.2 Gen 1 ports (4 x Type-A) |
| 2 x USB 2.0 ports | |
| Front USB | Total 6 ports, 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| ROG Supreme | FX 7.1-Channel High Definition Audio CODEC S1220A, - Impedance sense for front and rear headphone outputs, - Supports up to 32-Bit/192kHz playback*, Audio Features, - SupremeFX Shielding Technology, - Dual OP Amplifiers, - Premium audio capacitors, - Audio cover, 2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C®), 1 x Wi-Fi Module, 1 x DisplayPort, 1 x HDMI® port, 1 x Intel® I225-V 2.5G Ethernet, 1 x Optical S/PDIF out, 5 x Audio jacks, 1 x BIOS FlashBackTM butto, Fan and cooling related, 1 |
About this product
Description
- AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
- MD Ryzen™ 5000 and 3000 Series Desktop Processors
4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4666(O.C.)/4600(O.C.)/4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz, Un-buffered Memory *
- AMD Ryzen™ 5000 and 4000 G-Series Processors
4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4866(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz, Un-buffered Memory *
- ECC Memory (ECC mode) support varies by CPU.
- 1 x DisplayPort 1.2
- 1 x HDMITM port
- *Graphics specifications may vary between CPU types.
- AMD Ryzen™ 5000 and 3000 Series/ 5000 and 4000 G-Series Desktop Processors
- 1 x PCIe 4.0 x16 SafeSlot (supports x16 mode)
- AMD B550 chipset
- 1 x PCIe 3.0 x16 slot (supports x4 mode)*
- 3 x PCIe 3.0 x1 slots
- *Share bandwidth with PCIe3.0 x1_1, PCIe3.0 x1_2, PCIe3.0 x1_3
- Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
- M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)
- M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*
- 6 x SATA 6Gb/s ports
- Support RAID 0, 1, 10
- * When the M.2_2 Slot is populated , SATA6G_5/6 ports will be disabled.
- 1 x Intel® 2.5Gb Ethernet
- * WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later.
- 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
- - Jack-detection, Multi-streaming, Front Panel Jack-retasking
- - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
- * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 8-Channel audio.
- 1 x 20-3 pin System Panel header with Chassis intrude function
- - ASUS Q-LED (DRAM [yellow],CPU [red], VGA [white], Boot Device [yellow green)
