The details
| Brand | ASUS |
|---|---|
| Warranty | 3 Years Warranty |
| Socket Type | INTEL 1700 12TH 13TH 14TH GEN |
| Chipset | INTEL B760 |
| Opti | Mem II |
| 1 x Intel® 2.5Gb Ethernet | |
| ASUS LAN | Guard, Wireless & Bluetooth, Wi-Fi 6E, 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), Supports 2.4/5/6GHz frequency band*, Bluetooth® v5.3, Rear USB (Total 8 ports), 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 4 x USB 3.2 Gen 1 ports (3 x Type-A +1 x USB Type-C®), 3 x USB 2.0 ports (3 x Type-A), Front USB (Total 5 ports), 1 x USB 3.2 Gen 2 connector (supports USB Type-C®), 1 x USB 2.0 header supports additional 2 USB 2.0 ports |
| Audio | |
| ROG Supreme | FX 7.1-Channel High Definition Audio CODEC S1220A, - Impedance sense for front and rear headphone outputs |
| - Supports | Jack-detection, Multi-streaming, Front Panel Jack-retasking, - Supports up to 32-Bit/192 kHz playback*, Audio Features, - SupremeFX Shielding Technology, - Savitech SV3H712 AMP, - Premium audio capacitors, Back Panel I/O Ports, 1 x HDMI® port, 1 x DisplayPort, 1 x Wi-Fi Module, 5 x Audio jacks, Internal I/O Connectors, Fan and Cooling related, 1 x 4-pin CPU Fan header, 1 x 4-pin Chasis Fan header, 1 x 4-pin AIO Pump header, Power related, 1 x 24-pin Main Power connector, 1 x 8-pin +12V Power con |
Description
Let your rig run wild with the ROG Strix B760-I, a feisty foundation for your next SFF build. Boasting hyperfast DDR5 memory, low-latency WiFi 6E networking, and a future-ready PCIe 5.0 slot, it sets you up for savage speeds, all while giving you incredible 13th Gen support thanks to its powerful VRM and thermal solution.
Covering the power solution are two thick heatsinks with strategic airflow channels for increased heat dissipation while powering high-performance Intel 13th Gen processors.
- ROG STRIX B760-I GAMING WIFI
Intel® Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
- * Refer to www.asus.com for CPU support list.
- ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
- Chipset
- Intel® B760 Chipset
- Memory
2 x DIMM, Max. 96GB, DDR5 7600(OC)/ 7466(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*
- Dual Channel Memory Architecture
- Supports Intel® Extreme Memory Profile (XMP)
* Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
- * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
- Graphics
- 1 x DisplayPort**
- 1 x HDMI®***
- * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
- ** Support 4K@60Hz as specified in DisplayPort 1.4
- *** Support 4K@60Hz as specified in HDMI 2.1.
- Expansion Slots
- Intel® 13th & 12th Gen Processors*
- 1 x PCIe 5.0 x16 slot
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
- Storage
- Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel® 13th & 12th Gen Processors
- M.2_1 slot (Key M), type 2260/2280 (supports PCIe 4.0 x4 mode)
- Intel® B760 Chipset**
- M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- 4 x SATA 6Gb/s ports
- * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
- Ethernet
- * WiFi 6E 6GHz regulatory may vary between countries.
- 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
- - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- * Due to limitations in HAD bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
