INTEL LGA1851 15TH GENSocket Type
INTEL Z890Chipset
Specifications
The details
| Brand | ASUS |
|---|---|
| Socket Type | INTEL LGA1851 15TH GEN |
| Chipset | INTEL Z890 |
| 1 x Realtek 2.5Gb Ethernet | |
| ASUS LAN | Guard, Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Supports 2.4/5GHz frequency band, Bluetooth® v5.3*, Rear USB (Total 8 ports), 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)*, 3 x USB 10Gbps ports (3 x Type-A), 4 x USB 2.0 ports (4 x Type-A)***, Front USB (Total 9 ports), 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports*** |
| * USB Type-C® power delivery output | max. 5V/3A |
| ** USB Type-C® power delivery output | 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A, Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| - Supports | Jack-detection, Multi-streaming, Front Panel Jack-retasking, - Supports up to 24-Bit/192 kHz playback, Audio Features, - Audio Shielding, - Premium audio capacitors, - Dedicated audio PCB layers, 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode), 4 x USB 2.0 ports (4 x Type-A), 1 x DisplayPort, 1 x Wi-Fi module, 1 x Realtek 2.5Gb Ethernet port, 3 x Audio jacks, 1 x BIOS FlashBack™ button, Fan and Cooling Related, 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump hea |
About this product
Description
- Supports Intel® Core™ Ultra Processors(Series 2), LGA1851*
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
- Intel® Z890 Chipset
- 4 x DIMM slots, max. 256GB, DDR5
- Supports up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
- Dual channel memory architecture
- DIMM Fit
- Supports Intel® Extreme Memory Profile (XMP) memory module
- ASUS Enhanced Memory Profile III(AEMPIII)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product
- 1 x DisplayPort**
- 1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output***
- * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
- ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
- ***Supports max. 4K@120Hz as specified in DisplayPort 1.4.
- ****VGA resolution support depends on processors' or graphic cards' resolution.
*****While installing the operating system, please ensure that your monitor is connected to the DisplayPort on the back I/O panel or to a discrete graphics card.
- Intel® Core™ Ultra Processors(Series 2)*
- 1 x PCIe 5.0 x16 slot
- 2 x PCIe 4.0 x16 slots (supports x4 mode)
- 1 x PCIe 4.0 x16 slot (supports x1 mode)
- * Please check the PCIe bifurcation table on the support site
- Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel® Core™ Ultra Processors(Series 2) *
- M.2_1 slot (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode)
- M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
- M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 & SATA modes)
- 4 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5.
- 1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD/PPS Fast-charge )**
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
- 1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD/PPS Fast-charge )
