Specifications
The details
| Brand | Intel |
|---|---|
| Warranty | 03 YEAR WARRANTY |
| Memory Types Up to DDR | 5 4800 MT/s Up to DDR4 3200 MT/s |
| Package Specifications | |
| Sockets Supported FCLGA | 1700, Max CPU Configuration 1, Thermal Solution Specification PCG 2020C, TJUNCTION 100°C, Package Size 45.0 mm x 37.5 mm, Advanced Technologies, Intel® Gaussian & Neural Accelerator 3, Intel® Thread Director Yes, Intel® Deep Learning Boost (Intel® DL Boost) Yes, Intel® Speed Shift Technology Yes, Intel® Turbo Boost Max Technology 3.0 ‡ No, Intel® Turbo Boost Technology ‡ 2, Intel® Hyper-Threading Technology ‡ Yes, Intel® 64 ‡ Yes, Instruction Set 64-bit |
| Idle States Yes | |
| Enhanced Intel Speed | Step® Technology Yes, Thermal Monitoring Technologies Yes, Intel® Volume Management Device (VMD) Yes, Security & Reliability, Intel® Standard Manageability (ISM) ‡ Yes, Intel® Control-Flow Enforcement Technology Yes, Intel® AES New Instructions Yes, Secure Key Yes, Intel® OS Guard Yes, Execute Disable Bit ‡ Yes, Intel® Boot Guard Yes, Mode-based Execute Control (MBEC) Yes, Intel® Virtualization Technology (VT-x) ‡ Yes, Intel® VT-x with Extended Page Tables (EPT) ‡ Yes |
About this product
Description
- CPU Specifications
- Total Cores 10
- # of Performance-cores 6
- # of Efficient-cores 4
- Total Threads 16
- Max Turbo Frequency 4.60 GHz
- Performance-core Max Turbo Frequency 4.60 GHz
- Efficient-core Max Turbo Frequency 3.30 GHz
- Performance-core Base Frequency 2.50 GHz
- Efficient-core Base Frequency 1.80 GHz
- Cache 20 MB Intel® Smart Cache
- Total L2 Cache 9.5 MB
- Processor Base Power 65 W
- Maximum Turbo Power 148 W
- Supplemental Information
- Marketing Status Launched
- Launch Date Q1'23
- Embedded Options Available No
- Memory Specifications
- Max Memory Size (dependent on memory type) 128 GB
- Max # of Memory Channels 2
- Max Memory Bandwidth 76.8 GB/s
- Expansion Options
- Direct Media Interface (DMI) Revision 4
- Max # of DMI Lanes 8
- Scalability 1S Only
- PCI Express Revision 5.0 and 4.0
- PCI Express Configurations ‡ Up to 1x16+4 | 2x8+4
- Max # of PCI Express Lanes 20
- Instruction Set Extensions Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
