SOCKET 1700 14TH GENSocket Type
9-14900KProcessor Number i
5 5600 MT/sMemory Types Up to DDR
4 3200 MT/sUp to DDR
Specifications
The details
| Brand | Intel |
|---|---|
| Warranty | 03 YEARS WARRANTY |
| Socket Type | SOCKET 1700 14TH GEN |
| Processor Number i | 9-14900K |
| Memory Types Up to DDR | 5 5600 MT/s |
| Up to DDR | 4 3200 MT/s |
| Graphics Output e | DP 1.4b, DP 1.4a, HDMI 2.1 |
| Max Resolution (e | DP - Integrated Flat Panel) 5120 x 3200 @ 120Hz |
| Max # of PCI Express Lanes 20 | |
| Sockets Supported FCLGA | 1700, Max CPU Configuration 1, Thermal Solution Specification PCG 2020A, TJUNCTION 100°C, Package Size 45.0 mm x 37.5 mm, Intel® Gaussian & Neural Accelerator 3, Intel® Thread Director Yes, Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes, Intel® Speed Shift Technology Yes, Intel® Adaptive Boost Technology Yes, Intel® Thermal Velocity Boost Yes, Intel® Turbo Boost Max Technology 3.0 Yes, Intel® Turbo Boost Technology 2, Intel® Hyper-Threading Technology Yes, Intel® 64 ‡ Yes, Instruction S |
| Idle States Yes | |
| Enhanced Intel Speed | Step Technology Yes, Thermal Monitoring Technologies Yes, Intel® Volume Management Device (VMD) Yes, Intel® Standard Manageability (ISM) Yes, Intel® Control-Flow Enforcement Technology Yes, Intel® AES New Instructions Yes, Secure Key Yes, Intel® OS Guard Yes, Execute Disable Bit Yes, Intel® Boot Guard Yes, Mode-based Execute Control (MBEC) Yes, Intel® Virtualization Technology (VT-x) Yes, Intel® Virtualization Technology for Directed I/O (VT-d) Yes, Intel® VT-x with Extended Page Tables (EPT) Ye |
About this product
Description
- Product Collection Intel® Core™ i9 Processors (14th gen)
- Lithography Intel 7
- Total Cores 24
- Total Threads 32
- Max Turbo Frequency 6 GHz
- Intel® Thermal Velocity Boost Frequency 6 GHz
- Intel® Turbo Boost Max Technology 3.0 Frequency 5.8 GHz
- Performance-core Max Turbo Frequency 5.6 GHz
- Efficient-core Max Turbo Frequency 4.4 GHz
- Performance-core Base Frequency 3.2 GHz
- Efficient-core Base Frequency 2.4 GHz
- Max Memory Size (dependent on memory type) 192 GB
- Max # of Memory Channels 2
- Max Memory Bandwidth 89.6 GB/s
- ECC Memory Supported Yes
- Processor Graphics Intel® UHD Graphics 770
- Graphics Base Frequency 300 MHz
- Graphics Max Dynamic Frequency 1.65 GHz
- Execution Units 32
- Max Resolution (HDMI) 4096 x 2160 @ 60Hz
- Max Resolution (DP) 7680 x 4320 @ 60Hz
- Direct Media Interface (DMI) Revision 4
- Max of DMI Lanes 8
- Scalability 1S Only
- PCI Express Revision 5.0 and 4.0
- PCI Express Configurations Up to 1x16+4, 2x8+4
- Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
