AMD AM5Socket Type
INTEL X870Chipset
5Socket AM
1x HDMI™Onboard Graphics
Specifications
The details
| Brand | MSI |
|---|---|
| Warranty | 03 YEARS WARRANTY |
| Socket Type | AMD AM5 |
| Chipset | INTEL X870 |
| CPU | Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors |
| Socket AM | 5 |
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
| Memory Support DDR | 5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s |
| Onboard Graphics | 1x HDMI™ |
| Slot | 2x PCI-E x16 slot |
| 1x PCI-E x1 slot | |
| PCI | _E1 Gen PCIe 5.0 supports up to x16 (From CPU) |
| Audio | Realtek® ALC897, 7.1-Channel High Definition Audio |
| Storage | 3x M.2, 4x SATA 6G, M.2_1 slot (From CPU) |
| USB | 4x USB 2.0 (Rear), 6x USB 2.0 (Front), 2x USB 5Gbps Type A (Rear), 4x USB 5Gbps Type A (Front), 2x USB 10Gbps Type A (Rear), 1x USB 10Gbps Type C (Front), 1x USB 20Gbps Type C (Rear) |
| 1x USB 40Gbps Type C (Rear) | |
| LAN | 1x Realtek® 8126 5G LAN |
| Internal IO | 1x Power Connector(ATX_PWR), 2x Power Connector(CPU_PWR), 1x Power Connector(PCIE_PWR 8pin), 1x CPU Fan, 1x Combo Fan (Pump_Sys Fan), 6x System Fan, 1x EZ Conn-header (JAF_1), 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD), 1x Tuning Controller connector(JDASH), 3x Addressable V2 RGB LED connector (JARGB_V2), 1x RGB LED connector(JRGB), 1x TPM pin header(Support TPM 2.0), 2x Direct OC Jumper (JBCLK), 6x USB 2.0 ports, 4x USB 5Gbps Type A ports |
| 1x USB 10Gbps Type C ports | |
| WIRELESS LAN & BLUETOOTH | Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM |
| LED FEATURE | 4x EZ Debug LED |
| 1x EZ Memory Detection LED | |
| BACK PANEL PORTS | Clear CMOS Button, USB 5Gbps Type-A, USB 2.0, 5G LAN, Wi-Fi / Bluetooth |
| Audio connectors | |
| Flash B | IOS Button, HDMI™, USB 40Gbps Type-C, USB 10Gbps Type-A |
About this product
Description
- Supports AMD POR Speed and JEDEC Speed
- Supports Memory Overclocking and AMD EXPO™
- Supports Dual-Channel mode
- Supports Non-ECC, Un-buffered memory
- Supports CUDIMM, Clock Driver bypass mode only*
* CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility.
- Support HDMI™ TMDS 2.1, maximum resolution of 4K 60Hz*
- 1x Type-C DisplayPort
- USB4® port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 120Hz**
- *Available only on processors featuring integrated graphics
- **Graphics specifications may vary depending on the CPU installed
- M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
- M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices
- M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
- RAID•Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- *RAID 5 configuration is only supported by Ryzen™ 9000 / 7000 series processors.
- Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (160MHz) up to 2.9Gbps
* 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
